Summit White

Gideon Gray / After Dark, Coretec Seat Trim

AXLE, 3.47 FINAL DRIVE RATIO

ELEVATION PREFERRED EQUIPMENT GROUP includes standard equipment

WHEELS, 19" (48.3 CM) GLOSS BLACK ALUMINUM PAINTED

TIRES, 235/55R19, ALL-SEASON BLACKWALL

ELEVATION PREMIUM PACKAGE Includes (ZQ3) Convenience package II, (H9F) After Dark CoreTec seating or (HFL) Gideon Gray CoreTec seating and (PJI) wheels, 19" Technical Gray machined-face aluminum wheels

BLACK EDITION includes (PJO) 19" high gloss Black aluminum wheels, darkened grille and 'C' shaped surrounding bezel, black mirror caps, (V2P) Black roof-mounted side rails, Black exterior accents, (SFZ) Black GMC emblems, LPO and Black exterior badging.

CONVENIENCE PACKAGE II includes (A2X) 8-way power driver seat adjuster, (AL9) 2-way power driver lumbar seat adjuster, (CJ2) dual-zone automatic climate control, (ASV) sensor, cabin humidity and windshield temperature, (TCP) AutoSense liftgate, hands-free power programmable, (CE1) RainSense wipers, front intermittent, (CMO) Heated Wiper Park, (UG1) Universal Home remote, (K7A) Wireless phone charger for portable devices, (V2P) Roof rails, brushed aluminum and (VK8) Sunglass storage, overhead.

ROOF RAILS

WIPERS, RAINSENSE

HEATED WIPER PARK

LICENSE PLATE FRONT MOUNTING PACKAGE (will be forced on orders with ship-to states that require a front license plate)

LIFTGATE, AUTOSENSE, HANDS-FREE POWER PROGRAMMABLE

LPO, BLACK GMC EMBLEMS, FRONT AND REAR

WIRELESS PHONE CHARGING for portable devices

SEAT ADJUSTER, DRIVER 8-WAY POWER

SEAT ADJUSTER, 2-WAY POWER DRIVER LUMBAR CONTROL

UNIVERSAL HOME REMOTE includes garage door opener, 3-channel programmable

AIR CONDITIONING, DUAL-ZONE AUTOMATIC CLIMATE CONTROL with individual climate settings for driver and front passenger

SENSOR, CABIN HUMIDITY AND WINDSHIELD TEMPERATURE

SUNGLASS STORAGE, OVERHEAD

Vehicle Name - GMC Terrain

Body Style - Sport Utility

Drivetrain - All Wheel Drive

EPA Classification - Small Sport Utility Vehicle 4WD

Passenger Capacity - 5

Passenger Volume (ft?) - - TBD -

Base Curb Weight (lbs) - 3598

Tons/yr of CO2 Emissions @ 15K mi/year - 7.1

EPA Greenhouse Gas Score - 5

Fuel Economy Est-Combined - 25

EPA Fuel Economy Est - City (MPG) - 24

EPA Fuel Economy Est - Hwy (MPG) - 28

Dead Weight Hitch - Max Trailer Wt. (lbs) - 1500

Dead Weight Hitch - Max Tongue Wt. (lbs) - 150

Wt Distributing Hitch - Max Trailer Wt. (lbs) - 1500

Wt Distributing Hitch - Max Tongue Wt. (lbs) - 150

Engine Order Code - LSD

Engine Type - Turbocharged Gas I4

Displacement - 1.5L/90

Fuel System - Direct Injection

SAE Net Horsepower @ RPM - 175 @ 5800

SAE Net Torque @ RPM - 203 @ 2000-4000

Trans Order Code - MGH

Trans Type - 8

Trans Description Cont. - Automatic

Trans Description Cont. Again -

First Gear Ratio (:1) - - TBD -

Second Gear Ratio (:1) - - TBD -

Third Gear Ratio (:1) - - TBD -

Fourth Gear Ratio (:1) - - TBD -

Fifth Gear Ratio (:1) - - TBD -

Sixth Gear Ratio (:1) - - TBD -

Seventh Gear Ratio (:1) - - TBD -

Eighth Gear Ratio (:1) - - TBD -

Reverse Ratio (:1) - - TBD -

Clutch Size (in) -

Final Drive Axle Ratio (:1) - 3.47

Transfer Case Gear Ratio (:1), High - - TBD -

Transfer Case Gear Ratio (:1), Low - - TBD -

Cold Cranking Amps @ 0? F (Primary) - 760

Maximum Alternator Capacity (amps) - 130

Total Cooling System Capacity (qts) - - TBD -

Suspension Type - Front - McPherson Strut

Suspension Type - Rear - 4-Link

Suspension Type - Front (Cont.) -

Suspension Type - Rear (Cont.) -

Shock Absorber Diameter - Front (mm) - - TBD -

Shock Absorber Diameter - Rear (mm) - - TBD -

Stabilizer Bar Diameter - Front (in) - - TBD -

Stabilizer Bar Diameter - Rear (in) - - TBD -

Front Tire Order Code - QGS

Rear Tire Order Code - QGS

Spare Tire Order Code - QCL

Front Tire Size - 235/55R19

Rear Tire Size - 235/55R19

Spare Tire Size - T125/70R17

Front Wheel Size (in) - 19 x - TBD -

Rear Wheel Size (in) - 19 x - TBD -

Spare Wheel Size (in) - 17 x - TBD -

Front Wheel Material - Aluminum

Rear Wheel Material - Aluminum

Spare Wheel Material - Steel

Steering Type - Electric Rack & Pinion

Steering Ratio (:1), Overall - - TBD -

Lock to Lock Turns (Steering) - - TBD -

Turning Diameter - Curb to Curb (ft) - 37.1

Turning Diameter - Wall to Wall (ft) - - TBD -

Brake Type - Pwr

Brake ABS System - 4-Wheel

Disc - Front (Yes or ) - Yes

Disc - Rear (Yes or ) - Yes

Front Brake Rotor Diam x Thickness (in) - 16 x - TBD -

Rear Brake Rotor Diam x Thickness (in) - 16 x - TBD -

Drum - Rear (Yes or ) -

Rear Drum Diam x Width (in) -

Fuel Tank Capacity, Approx (gal) - 15.6

Front Head Room (in) - 39.5

Front Leg Room (in) - 43.95

Front Shoulder Room (in) - 57.69

Front Hip Room (in) - 55.25

Second Head Room (in) - 37.8

Second Leg Room (in) - 39.7

Second Shoulder Room (in) - 55.7

Second Hip Room (in) - 51

Wheelbase (in) - 107.48

Length, Overall (in) - 181

Width, Max w/o mirrors (in) - 74.5

Height, Overall (in) - - TBD -

Track Width, Front (in) - 63.79

Track Width, Rear (in) - 63.87

Min Ground Clearance (in) - 5.75

Rear Door Opening Height (in) - - TBD -

Rear Door Opening Width (in) - - TBD -

Cargo Area Length @ Floor to Seat 1 (in) - - TBD -

Cargo Area Length @ Floor to Seat 2 (in) - - TBD -

Cargo Area Length @ Floor to Seat 3 (in) -

Cargo Area Width @ Beltline (in) - - TBD -

Cargo Box Width @ Wheelhousings (in) - - TBD -

Cargo Box (Area) Height (in) - - TBD -

Liftover Height (in) - - TBD -

Cargo Volume to Seat 1 (ft?) - 63.5

Cargo Volume to Seat 2 (ft?) - 29.8

Cargo Volume to Seat 3 (ft?) -

Model Group - Terrain

Vehicle Segment - Compact Sport Utility

Vehicle Type - Sport Utility

Engine Displacement Units - 1.5

Engine Camshaft - DOHC

Engine Block Type - aluminum

Engine Cylinder Count - 4

Engine Valve Count - 4

Country of Origin - Mexico GMK Truck Trucks - MPV
