Silver Ice Metallic

Jet Black, Cloth Seat Trim

EMISSIONS, CONNECTICUT, DELAWARE, MAINE, MARYLAND, MASSACHUSETTS, NEW JERSEY, NEW YORK, OREGON, PENNSYLVANIA, RHODE ISLAND, VERMONT AND WASHINGTON STATE REQUIREMENTS

REAR AXLE, 3.73 RATIO

LT PREFERRED EQUIPMENT GROUP includes standard equipment

WHEELS, 18" (45.7 CM) MACHINED ALUMINUM with Silver painted accents, 6-spoke

TIRES, LT275/70R18E ALL-TERRAIN, BLACKWALL

TIRE, SPARE LT275/70R18 ALL-TERRAIN, BLACKWALL

SEATS, FRONT 40/20/40 SPLIT-BENCH with covered armrest storage and under-seat storage (lockable)

ALL STAR EDITION for Crew Cab and Double Cab models, includes (PCL) Convenience Package and (PQB) Safety Package

Z71 OFF-ROAD AND PROTECTION PACKAGE includes (Z71) Off-Road suspension with off-road tuned twin tube shocks, (JHD) Hill Descent Control and (NZZ) skid plates (transfer case and oil pan), (CGN) Chevytec spray-on bedliner, (AAK) All-weather Z71 floor liners, LPO, Z71 grille insert (replaces Bowtie emblem) and Z71 fender badge (replaces "4X4" decal on bed) Includes (PYV) 18" machined aluminum wheels and (QF6) LT275/70R18E all-terrain, blackwall tires.

CONVENIENCE PACKAGE includes (CJ2) dual-zone automatic climate control, (A2X) 10-way power driver seat including power lumbar, (KA1) heated driver and passenger seats, (KI3) heated steering wheel, (N37) manual tilt/telescoping steering column, (C49) rear-window defogger, (ATH) Keyless Open and Start, (NP5) leather-wrapped steering wheel, (N06) steering column lock, (BTV) Remote Start, (UTJ) content theft alarm, (QT5) EZ Lift power lock and release tailgate, (UF2) bed LED cargo area lighting, (T3U) LED fog lamps, (B1J) rear wheelhouse liners, (AZ3) front 40/20/40 split-bench with under-seat storage, (KPA) auxiliary power outlet, (USS) 2 charge-only USB ports for second row

SAFETY PACKAGE includes (UD5) Front and Rear Park Assist, (UKC) Lane Change Alert with Side Blind Zone Alert and (UFG) Rear Cross Traffic Alert

SNOW PLOW PREP/CAMPER PACKAGE includes (KW5) 220-amp alternator, includes increased front GAWR on Heavy Duty models, (NZZ) skid plates (transfer case and oil pan), pass through dash grommet hole and roof emergency light provisions. Contact GM Upfitter Integration at www.gmupfitter.com for plow installation details and assistance.

Z71 OFF-ROAD PACKAGE includes (Z71) Off-Road suspension with off-road tuned twin tube Rancho shocks, (JHD) Hill Descent Control and (NZZ) skid plates (transfer case and oil pan) Includes (QXT) LT265/70R17 all-terrain, blackwall tires and molded in color grille with Z71 logo.

HILL DESCENT CONTROL

ALTERNATOR, 220 AMPS

TRAILERING WIRING PROVISIONS for trailering, 5th wheel and gooseneck trailer, includes additional 7-way wiring harness located at the rear of the pickup bed attached to the rear frame cross member

SKID PLATES protect the oil pan, front axle and transfer case

WHEELHOUSE LINERS, REAR

LED CARGO AREA LIGHTING located in pickup bed, activated with switch on center switch bank or key fob

FOG LAMPS, FRONT, LED

LAMPS, SMOKED AMBER ROOF MARKER, (LED)

MIRRORS, OUTSIDE POWER-ADJUSTABLE VERTICAL TRAILERING WITH HEATED AND AUTO-DIMMING UPPER GLASS lower convex mirrors, turn signal indicators, puddle lamps, perimeter lighting, auxiliary lighting, power folding/manual extending (extends 3.31" [84.25mm]) Includes (DD8) auto-dimming rearview mirror.)

CHEVYTEC SPRAY-ON BEDLINER Black with Chevrolet logo (does not include spray-on liner on tailgate due to Black composite inner panel)

LICENSE PLATE KIT, FRONT

TAILGATE, GATE FUNCTION MANUAL WITH EZ LIFT includes power lock and release

SEATING, HEATED DRIVER AND FRONT OUTBOARD PASSENGER

LPO, ALL-WEATHER FLOOR LINERS 1st and 2nd rows, (includes Z71 logo on front mats)

STEERING WHEEL, LEATHER-WRAPPED

STEERING WHEEL, HEATED

STEERING COLUMN, MANUAL TILT AND TELESCOPING

STEERING COLUMN, LOCK CONTROL, ELECTRICAL

REMOTE VEHICLE STARTER SYSTEM

KEYLESS OPEN AND START

THEFT-DETERRENT SYSTEM, UNAUTHORIZED ENTRY

USB PORTS, DUAL, CHARGE-ONLY (2ND ROW)

POWER OUTLET, REAR AUXILIARY, 12-VOLT

AIR CONDITIONING, DUAL-ZONE AUTOMATIC CLIMATE CONTROL

DEFOGGER, REAR-WINDOW ELECTRIC

MIRROR, INSIDE REARVIEW AUTO-DIMMING

FRONT AND REAR PARK ASSIST, ULTRASONIC

REAR CROSS TRAFFIC ALERT

LANE CHANGE ALERT WITH SIDE BLIND ZONE ALERT

Vehicle Name - Chevrolet Silverado 2500HD

Body Style - Crew Cab Pickup

Body Code - E63

Drivetrain - Four Wheel Drive

Passenger Capacity - 6

Number of Passenger Doors -

Gross Axle Wt Rating - Front (lbs) - 5600

Gross Axle Wt Rating - Rear (lbs) - 6600

Curb Weight - Front (lbs) - 3849

Curb Weight - Rear (lbs) - 2784

Gross Vehicle Weight Rating Cap (lbs) - 10650

Fuel Economy Est-Combined (MPG) -

EPA Fuel Economy Est - City (MPG) -

EPA Fuel Economy Est - Hwy (MPG) -

Gross Combined Wt Rating (lbs) - 24000

Dead Weight Hitch - Max Trailer Wt. (lbs) - 5000

Dead Weight Hitch - Max Tongue Wt. (lbs) - 500

Wt Distributing Hitch - Max Trailer Wt. (lbs) - 14500

Wt Distributing Hitch - Max Tongue Wt. (lbs) - 1450

Fifth Wheel Hitch - Max Trailer Wt. (lbs) - - TBD -

Fifth Wheel Hitch - Max Tongue Wt. (lbs) - - TBD -

Maximum Trailering Capacity (lbs) - 18500

Engine Order Code - L8T

Engine Type - Gas V8

Displacement - 6.6L/400

Fuel System - Direct Injection

SAE Net Horsepower @ RPM - 401 @ 5200

SAE Net Torque @ RPM - 464 @ 4000

Trans Order Code - MYD

Trans Type - 6

Trans Description Cont. - Automatic

Trans Description Cont. Again -

First Gear Ratio (:1) - 4.03

Second Gear Ratio (:1) - 2.36

Third Gear Ratio (:1) - 1.53

Fourth Gear Ratio (:1) - 1.15

Fifth Gear Ratio (:1) - 0.85

Sixth Gear Ratio (:1) - 0.67

Seventh Gear Ratio (:1) -

Eighth Gear Ratio (:1) -

Ninth Gear Ratio (:1) -

Tenth Gear Ratio (:1) -

Reverse Ratio (:1) - 3.06

Clutch Size (in) -

Trans Power Take Off -

Trans PTO Access -

Transfer Case Model - Magna MP3023/4

Transfer Case Gear Ratio (:1), High - 1.00

Transfer Case Gear Ratio (:1), Low - 2.69

Transfer Case Power Take Off -

Cold Cranking Amps @ 0? F (Primary) - 720

Cold Cranking Amps @ 0? F (2nd) - 730

Tons/yr of CO2 Emissions @ 15K mi/year -

Maximum Alternator Capacity (amps) - 220

Maximum Alternator Watts -

Total Cooling System Capacity (qts) - - TBD -

Engine Oil Cooler - Yes

Frame Type - Hydroformed

Suspension Type - Front - Short/Long Arm

Suspension Type - Rear - Multi-Leaf Springs

Spring Capacity - Front (lbs) - - TBD -

Spring Capacity - Rear (lbs) - - TBD -

Axle Type - Front - - TBD -

Axle Type - Rear - - TBD -

Axle Capacity - Front (lbs) - - TBD -

Axle Capacity - Rear (lbs) - - TBD -

Axle Ratio (:1) - Front - 3.73

Axle Ratio (:1) - Rear - 3.73

Shock Absorber Diameter - Front (mm) - 51.0

Shock Absorber Diameter - Rear (mm) - 51.0

Stabilizer Bar Diameter - Front (in) - 1.38

Stabilizer Bar Diameter - Rear (in) -

Front Tire Order Code - QF6

Rear Tire Order Code - QF6

Spare Tire Order Code - ZYG

Front Tire Size - LT275/70R18E

Rear Tire Size - LT275/70R18E

Spare Tire Size - LT275/70R18

Front Tire Capacity (lbs) - 3020

Rear Tire Capacity (lbs) - 3351

Spare Tire Capacity (lbs) - 3638

Revolutions/Mile @ 45 mph - Front (Rev/Mile) - - TBD -

Revolutions/Mile @ 45 mph - Rear (Rev/Mile) - - TBD -

Revolutions/Mile @ 45 mph - Spare (Rev/Mile) - - TBD -

Front Wheel Size (in) - 18 x 8.0

Rear Wheel Size (in) - 18 x 8.0

Spare Wheel Size (in) - 18 x 8.0

Front Wheel Material - Aluminum

Rear Wheel Material - Aluminum

Spare Wheel Material - Steel

Steering Type - Pwr

Steering Ratio (:1), On Center - - TBD -

Steering Ratio (:1), At Lock - - TBD -

Turning Diameter - Curb to Curb (ft) - 52.7

Turning Diameter - Wall to Wall (ft) -

Brake Type - Pwr

Brake ABS System - 4-Wheel

Brake ABS System (Second Line) -

Disc - Front (Yes or ) - Yes

Disc - Rear (Yes or ) - Yes

Front Brake Rotor Diam x Thickness (in) - 14.0 x 1.6

Rear Brake Rotor Diam x Thickness (in) - 14.1 x 1.3

Drum - Rear (Yes or ) -

Rear Drum Diam x Width (in) -

Fuel Tank Capacity, Approx (gal) - 36

Aux Fuel Tank Capacity, Approx (gal) -

Fuel Tank Location - - TBD -

Aux Fuel Tank Location -

Front Head Room (in) - 43.03

Front Leg Room (in) - 44.53

Front Shoulder Room (in) - 66.02

Front Hip Room (in) - 61.18

Second Head Room (in) - 40.12

Second Leg Room (in) - 43.4

Second Shoulder Room (in) - 65.3

Second Hip Room (in) - 60.24

Wheelbase (in) - 158.94

Length, Overall (in) - 249.95

Width, Max w/o mirrors (in) - 81.85

Height, Overall (in) - 79.82

Overhang, Front (in) - - TBD -

Overhang, Rear w/o bumper (in) - - TBD -

Front Bumper to Back of Cab (in) - - TBD -

Cab to Axle (in) - 42.1

Cab to End of Frame (in) - - TBD -

Ground to Top of Load Floor (in) - - TBD -

Ground to Top of Frame (in) - - TBD -

Frame Width, Rear (in) - - TBD -

Ground Clearance, Front (in) - 10.12

Ground Clearance, Rear (in) - 10.12

Cargo Box Length @ Floor (in) - 82.25

Cargo Box Width @ Top, Rear (in) - - TBD -

Cargo Box Width @ Floor (in) - 71.4

Cargo Box Width @ Wheelhousings (in) - 51.85

Cargo Box (Area) Height (in) - 21

Tailgate Width (in) - - TBD -

Cargo Volume (ft?) - 69.5

Ext'd Cab Cargo Volume (ft?) - - TBD -

Model Group - Silverado HD

Vehicle Segment - Large Pick-up

Vehicle Type - Crew Cab

Body Cab Style - Crew Cab

Bed Style - regular

Engine Displacement Units - 6.6

Engine Camshaft - OHV

Engine Block Type - iron

Engine Cylinder Count - 8

Engine Valve Count - 2

Country of Origin - United States Chevrolet Trucks
